Computer-controlled cutting of sheet materials, including plywood, veneer, plastic, comatex and others, to create 2D and 3D objects from vector graphics or digital 3D models. You can make housings, furniture, design objects, fasteners, fixtures and everything else that is possible with 2D and 3D cutting of sheet materials.

Technical specification

• Material type - Plywood, Veneer, Plastic, Comatex and other.
• Max work zone - 2m/3m/20cm
• Other - Available 4th axle, equipped with vacumtable

Light metal and plastic 4-axis CNC machine. The maximum size of the workpiece is 600x400x200mm. Possibility to make various designs from a 3D model with very high precision. Accuracy up to 10 μm. The machine works with high shafts around the rotation, which makes the end surface of the material mirror smooth, eliminating the need for post-processing. It is possible to produce - design parts, mechanical elements, embossing plates, electronics housings and high-reliability product samples.

Technical specification

• Can cut - Aluminium, Copper, Silver, Bronze, and other metals and plastics
• Precision - 10μm (0.01mm)
• RPM - 40 000
• Cooling - Etanol base
• Max product size - 500mm/400mm/200mm

Production of 3D objects using FDM and UV LCD printing technology. A 3D scanner is also available.

Technical specification

LPD printer:

• Bed - 265x265x300 mm
• Layer resolution - 0.15-0.2 mm
• Materials - ABS, HIPS, NYLON, PETG, PLA ect.

UV LCD printer:

• Bed - 132x74x175 mm
• Layer resolution - 0.05 mm
• Materials - Resin

Scanner:

• Max product size - ~ 200mm/200mm/200mm

Solidworks and SolidCam. For technical drawing of 2D / 3D objects and preparation of CNC files.

Soldering of electronic components on printed circuit boards. Soldering of wires and connectors.

"Accessories" for the manufacture of complex products.

Electric welding, MIG, TIG welding device with and without gas for welding of steel structures and parts up to 12 mm thick.

Industrial painting booth for spray painting with a paint pistol in a controlled environment with low dust content and installed fume extraction. It is possible to prim, paint and varnish parts using water-based, alkyd and solvent-based paints, car paints and other "wet" paints.

Technical specification

• Possible - To Prim, Paint & Varnish parts
• Paint types - Water-based, Alkyd, Solvent-based paints, car paints, other "wet" paints
• Booth dimensions - 2m/3m/2m (width / length / height)
• Other - Equipped with infrared lamps for faster paint drying

"Accessories" for the -production and assambly of complex products - drilling machine, grinder, pneumatic tools, hand tools.

For processing of all types of timber, including conifers, fruit trees, cork and others, - for elongation, thickness planing, surface milling, edge planing, painting.

Technical specification

• Processing options - Cutting, thickness planing, surface milling, edge trimming, dowel pin mortising
• Saw tilt angel - ≥ 90°/45°
• Saw MAX cut - 90° - 100mm
• Thicknessers MAX size - width - 400mm, thickness - 230mm
• Surface planer - width < 410mm, MIN length - 15mm
• Router size - depth < 32mm, width - 4-15mm
